Electronic scroll screen suitable for slip ring

Automation Equipment2024-08-09

In today's rapidly developing technology, electronic devices are becoming increasingly intelligent and portable. Among them, electronic scrolling technology has become a new star in the field of display technology due to its unique foldability and portability. Behind this technology, slip rings play a crucial role.

As the name suggests, an electronic scroll screen is a display screen that can be curled and unfolded. The flexibility and portability of this display screen make it widely applicable in portable electronic devices. Especially in the film and television, cultural and artistic industries, we often see their presence. And slip ring technology is the key to achieving flexibility in electronic screen rolling.

The working principle of electronic scroll screen is to drive the lamp body to rotate through the rotating shaft of the motor. The rotation speed is generally fast, so internal wires are prone to problems such as entanglement and wire burning. JINPAT has conducted extensive research on anti winding and wire burning technology for screen slip rings, which can effectively prevent such problems and achieve free curling and unfolding of electronic screens. JINPAT often uses a gold to gold contact method on the contact points of the rolling screen slip ring, which not only ensures low contact resistance but also significantly extends the product's service life. Stainless steel is commonly used on the outer shell of the rolling screen slip ring to increase its corrosion resistance and ensure reliable operation of the slip ring in various external environments.


The structure design of the electronic roll screen slip ring is relatively compact, with an outer diameter of only 20mm and a length of 50mm. Although the volume is not large, it can accommodate 100 circuit paths, which can well meet the needs of compact, convenient and multifunctional communication of the product. The compact design allows the slip ring to be easily integrated into the narrow space of electronic screens. 50 thin coaxial cables are used inside the slip ring of the electronic roll screen, which can transmit high-definition video signals and ensure clear and smooth display effects when the electronic roll screen is unfolded.

The development of slip ring technology not only promotes the innovation of electronic screen rolling technology, but also brings more convenience to our daily lives. With the continuous advancement of technology, we have reason to believe that electronic scrolling screens will become more popular in the future, and slip rings will continue to silently support this transformation behind the scenes.
